Everything I Wish I Knew About Stress Marks When I Started Building Gunpla

A stress mark, circled, on my HG Io Frame.

You’re relaxing and building Gunpla when it happens.

The piece you’ve cut out is red all over—except for a white spot where you cut it out from the sprue. Now you have to live with it.

Over the years I’ve learned a lot about these odd white spots, called stress marks, that occur when you build Gunpla. Here’s everything I wish I knew when I started.

Stress marks come from pinched, or “stressed” plastic.

I used to think that there was a vein of white plastic inside every Gunpla sprue. It turns out that Gunpla parts are all monocolored, they just can turn pale when they’re warped.

The white area you see here is a reaction to being cut.

Sometimes that happens before you get the kit—maybe it was jostled in the mail and has some slight white streaking where larger parts warped or bent. But usually, stress marks happen while you’re building and you manipulate the plastic with your nippers.

Cutting further away from the plastic can reduce stress marks.

Have you ever wondered why a lot of Gunpla builders don’t cut close to the piece? Instead they leave some space. My technique goes like this: cut a few millimeters away, then make a second cut (with a God Hand or an X-Acto knife) to fully remove the piece. I end up with a big pile of little plastic beads in the end!

Nippers + X-Acto knife = nubs!

This is partly to get a clean cut, but it also reduces stress marks. When you do this, the stress mark from pinched plastic is more likely to occur on the sprue instead of the piece.

Cutting “backwards” can keep stress marks from appearing.

This is another technique for making the stress mark appear on the sprue instead of the Gunpla piece that I learned from our contributor, Milky. Milky says, “I always turn the nippers around when cutting the part instead of flush against it. This way the marks go the other way.”

This still leaves a nub, which Milky gets rid of by sanding.

Sanding can reduce the appearance of stress marks.

Gunpla feet are my problem area when it comes to stress marks. I always get the worse ones there, perhaps because feet are such big parts that they have big connectors to the sprue. But I’ve found that by sanding them down, I can reduce their visibility.

Before and after.

Here’s an example of an HG Io Frame kit that I sanded down with some auto sandpaper. The unstressed nub has all but disappeared, and the stressed nub is slightly improved. It’s still pale, sure, but it’s not as much of an eyesore.

To make this even less noticeable, I could apply matte top-coat. That would make sure the plastic is no longer reflective, and it would make the sanding scuff marks less visible, too.

But the only way to get rid of stress marks completely is to paint.

Unfortunately, if you have stress marks on your Gunpla and want to make them disappear, there’s only one way to do it—painting. Painting is a double challenge because if your kit isn’t completely, perfectly sanded and smooth first, your nub marks will be more noticeable.

For now, I’ve learned to live with my stress marks. I build Gunpla to relax and my kits aren’t designed for tournaments or contests. If I wanted a completely perfect Gunpla, I would buy a figure or commission a pro like Milky or Ashe to make me one.

I hope these techniques help you figure out why stress marks happen and make them occur a little less often but—and I’ve been waiting the entire article to say this—don’t stress about stress marks.


Previous Post
Gunpla Pre-orders and New Releases for April-May 2017
Next Post
Step up your Gunpla: How to clean Gunpla

Related Posts

No results found

6 Comments. Leave new

  • Ultra fine automotive sandpaper is your friend.

  • One other thing I do with stress marks is that I use my fingernails and rub the stress mark a bit, if it’s something flush like an x-acto knife cut, it helps surprisingly well at times.

    • Tsorovan Zero
      June 4, 2017 4:43 pm

      Fingernails can also reduce the appearance of sanding scratches and is good for checking if your nub removal is 100% clean. It’s definitely a good technique to use.

  • Kitchen Wolf
    May 19, 2017 12:35 pm

    This is probably fundamental enough that you just didn’t think to mention it, but how you use the knife matters. The stress marks come from tension (stretching when another piece is crushed). If you use the knife like you would a razor when shaving, that maximizes the tensile forces on either side of the cut (which may not matter if it’s sharp enough). If the knife is used the way you would a santoku, like this:

    The blade slides forward to take advantage of shearing forces. If the knife is dull, it won’t cut, but it won’t try to crush its way through and leave the frosting effect either. The disadvantage to this over nippers is that you also need to control where the blade goes after it cuts what you want.

  • Tsorovan Zero
    June 4, 2017 4:40 pm

    Real Touch markers can reduce stress mark visibility if you go over it with a closely related color. The darker the plastic color, the easier it is to hide it this way. Instead of a white mark, you get one that’s slightly off shade of your part’s color.

  • Amishpriest
    June 5, 2017 11:44 am

    Got a bit of a challenge right now working on Char’s Zaku I, but going carefully and using these tips is helping. Still new at this so I’m hoping it turns out well.
